Kyn28-24 24kv Medium Voltage Switchgear Switchgear Metal Shell

KYN28 indoor metal-cladKYN28 indoor metal-clad withdrawable switchgear(hereafter short as switchgear) is a complete power distribution device for 3.6~24KV, 3 phase AC 50Hz, single bus sectionalized system. It is main used for power transmission of middle/small generators in power plants, power receiving, transmission for su

Featured Products

KYN28 indoor metal-clad

KYN28 indoor metal-clad withdrawable switchgear(hereafter short as switchgear) is a complete power distribution device for 3.6~24KV, 3 phase AC 50Hz, single bus sectionalized system. It is main used for power transmission of middle/small generators in power plants, power receiving, transmission for substations in power distribution and power system of factories, mines and enterprises, and starting of large high-voltage motor, etc, so as to control, protect and monitor the system. The switchgear meets IEC298, GB3906-91. In addition to be used with domestic VS1 vacuum circuit breaker, it can be used with VD4 from ABB, 3AH5 from Siemens domestic ZN65A, and VB2 from GE, etc. It is truly a power distribution deviece with good performance.

In order to meet the requirement for wall mounting and front-end maintenance, the switchgear is equipped with a special current transformer, so that the operator can maintain and inspect it in front of the cubicle.



Main technical specifications

No.ItemUnitParameters
1Rated VoltageKV12
2Rated FrequencyHz50/60
3Rated CurrentA630 1250 1600 2000 2500 3150
4Branch busbar rated currentA630 1250 1600 2000 2500 3150
5Main busbar rated currentA630 1250 1600 2000 2500 3150
61min power frequency withstand voltageDryKV3850/60
4860/65
Wet
7Lightening impulse withstand voltageKV7595/125
8Rated Short-time Withstand Current (4s)KA20/25/31.5/40
9Rated Short Circuit Breaking Current(Peak)KA40/50/63/80/100
10Protection type IP4X for housing
