High voltage/low voltage/medium voltage electrical switchgear power distribution GGD switchgear

GGD type fixed enclosed low-voltage switchgear is suitable for the power station, substation, industrial and mining enterprises and other power users. AC 50/60 Hz, rated working voltage to 660V, rated working current to 3150A. As power conversion, distribution and control for power, lighting and distribution equipment in a 50kA

Featured Products

GGD type fixed enclosed low-voltage switchgear is suitable for the power station, substation, industrial and mining enterprises and other power users. AC 50/60 Hz, rated working voltage to 660V, rated working current to 3150A. As power conversion, distribution and control for power, lighting and distribution equipment in a 50kA power distribution system.

This product complies with IEC43-1 international standard, GB7251-1 national standard and JB/T9661 machinery industry standard.
HV/LV/MV Electric Switch Equipment Power Distribution GGD Switchgear

Our low-voltage switchgear equipment covers GGD, GCK, GCS, GGJ, GDF fixed partition, MNST, 8PT Siemens authorization, XL-21 power cabinet, XL distribution box, XM lighting distribution box, XC metering box, JP low-voltage integrated distribution box , XFW low voltage cable branch box, DXW terminal box.   GCK, GCS, GDF, GGD, GGJ low-voltage complete sets of equipment shell protection level can meet the maximum IP41.

HV/LV/MV Electric Switch Equipment Power Distribution GGD Switchgear

HV/LV/MV Electric Switch Equipment Power Distribution GGD Switchgear
ItemData
Rated operational voltage(V)AC 380 (400),660 (690)
Rated voltage of auxiliary circuit(V)AC 220,380 (400)
DC 110,220
Rated frequency(Hz)50/60
Rated insulation voltage(V)660 (690)
Horizontal bus rated current(A)≤3150A
Main bus rated short-time withstand current(kA/1s)15, 30, 50
Bus rated peak withstand current(kA)30, 63, 105
Dielectric test voltage(V/1 min)2500
BusThree-phase four-wire systemA, B, C, PEN
Three-phase five-wire systemA,B,C,PE,N
IP gradeProtect against solid foreign matter with a diameter of no less than 2. 5mmIP30

Overall Size (mm)
Height(H)Width(W)Depth(D)
2200600600
2200600800
2200800600
2200800800
22001000600
22001000800
22001200600
22001200800

Structural Feature
1. Cabinet structure
The body of the GGD cabinet adopts the form of a general cabinet, and the frame is assembled by partial welding of 8MF cold-formed steel. The parts of the general cabinet are designed according to the principle of the module, and there are 20-mold mounting holes. The general coefficient is high, which can make the factory realize large Mass production. The GGD cabinet is designed with full consideration of the heat dissipation problem during the operation of the cabinet. There are different numbers of heat dissipation slots at the upper and lower ends of the cabinet, so that the sealed cabinet forms a natural ventilation channel from bottom to top to achieve the purpose of heat dissipation. According to the requirements of modern industrial product art design, GGD cabinet adopts the golden ratio method to design the cabinet shape and the division size of each part to make the whole cabinet beautiful and generous. The cabinet door is connected with the cabinet body with a hinged hinge, which is easy to install and disassemble. A mountain-shaped rubber-plastic strip is embedded outside the folding edge of the door to prevent direct collision between the door and the cabinet body and improve the protection level of the door; The GGD cabinet uses HD13BX and HS13BX rotary operating knife switches, which enable the operating door of the cabinet to be opened, which is convenient for manufacturing and maintenance. The top cover of the cabinet can be removed when needed to facilitate the assembly and adjustment of the main busbar on site. The four corners of the cabinet top are equipped with lifting rings for lifting and installation; The protection level of the cabinet is IP30, and it can also be selected between IP20-IP40 according to user requirements.

2.Busbar System
The main bus of the device configuration is placed on the upper part of the cabinet. The cabinet is equipped with an independent PE protective grounding system and N neutral conductor, both of which run through the entire device. The neutral bus bar and the protective grounding bus bar are installed parallel to the lower part of the cabinet, and there are holes on the PE/N row. The protective grounding or neutral cables of each loop can be connected nearby. If the N wire and PE wire are separated by an insulator, the N wire and PE wire are used separately. If in a three-phase four-wire system, the neutral bus and the protective grounding bus share the same bus (PEN line). In order to further improve the dynamic stability of the main circuit, a ZMJ type combined bus clamp and insulation support for the GGD cabinet are designed. The busbar clamp is made of high-strength, high flame-retardant PP0 alloy material, with high insulation strength, good self-extinguishing performance, and unique structure: it can be easily combined into a single busbar clamp or a double busbar clamp by adjusting the building block. The insulating support is a sleeve type molded structure with low cost and high strength. The busbar connection in the cabinet is connected with fasteners, and the screw should face the back of the cabinet (see installation and debugging requirements for specific requirements)

3.Protective grounding system
The cabinet frame is welded with grounding bolts to connect with the grounding bar that penetrates the entire cabinet. The instrument door equipped with electrical components is connected to the frame with multiple strands of soft copper wire. The mounting parts in the frame and the frame are connected with knurled screws to make The whole cabinet becomes a complete grounding protection circuit.


HV/LV/MV Electric Switch Equipment Power Distribution GGD Switchgear
HV/LV/MV Electric Switch Equipment Power Distribution GGD Switchgear


HV/LV/MV Electric Switch Equipment Power Distribution GGD Switchgear


HV/LV/MV Electric Switch Equipment Power Distribution GGD SwitchgearHV/LV/MV Electric Switch Equipment Power Distribution GGD Switchgear

FAQ

Q: Are you the manufacturer or trader?
A: We are both manufacturer & trader. We have our own manufacturer named TIANYI TONGYI ELECTRIC CO.,LTD, who have 27 years experience in electric industry. It covers an totally area of 117,000 m2 with 300 employees, also is a qualified supplier of China National Nuclear Corporation(CNNC) and main supplier for State Grid & China Southern Power Grid.

Q: What is your after-sales service?
A: We always provide free online service and technical support within 24 hours. 18 months warranty for customers.

Q: What is your delivery time?
A: Normally 25~35days. It depends on the order quantity and season. We have very strong capacity to produce top quality products, please inquiry us if you have any questions.

Q: What is the quality warranty time?
A: We have quality certificate CCC, CQC, ISO9001, CE ... Meanwhile, we can provide 18 months warranty for our products. Free online service and technical support within 24 hours is always provided to our customers.

Q: Do you accept ODM and OEM?
A: Yes. We have professional R & D teams to update and develop the latest technology. We also can support ODM or OEM, please send us details drawing to discuss.

Q: What is your payment terms?
A: Generally there are two payment terms:
  1.  30% advance payment via T/T as a deposit, balance 70% against the shipping documents
  2.  Irrevocable L/C at sight

Q: If I want to visit you, how to go?
A: Our factory is located in Luoyuan County, Fuzhou City. Details address is Songshan Area, Taiwan Investment Zone, Luoyuan County, Fuzhou City, Fujian Province,China.
  1. The nearest airport is Fuzhou Airport, if you come by air, please arrive in Fuzhou Airport, it takes 1 hour from the airport to our factory
  2. The nearest train station is Luoyuan Station, if you come by train, please arrive in Luoyuan Station, it takes only 5 minutes to our factory.
Anyway, please contact us in advance, we will send the car to the airport or train station to pick you up.Sincerely welcome you to come and visit us.

Q: Do you need agents?
A: Yes, we welcome you to be a partner. Welcome to contact us for more information.
