Ggd Series Low Voltage Fixed Electrical Switch Panel Board Cabinets
Technical Specification:
Product Description:
GGD, GCS, MNS AC low-voltage distribution switchgear is suitable for power plants, substations, industrial and mining enterprises and other power users as the distribution system with AC 50Hz, rated voltage 380V and rated current to 3150A.
Product Specification:
Technical Specification:
| Item | Unit | Parameter |
| Rated voltage | V | 380 |
| Rated current | A | 1000 |
| Rated short-circuit breaking current | KA | 15 |
| Rated short-circuit withstand current | KA | 15 |
| Rated peak withstand current | KA | 30 |
GGD, GCS, MNS AC low-voltage distribution switchgear is suitable for power plants, substations, industrial and mining enterprises and other power users as the distribution system with AC 50Hz, rated voltage 380V and rated current to 3150A.
Product Specification:
| Current Voltage | 380V |
| Rated Current | 3150A |
| Working frequency | 50HZ |
| Current | AC |
| Altitude | ≤2000m |
| Ambienttemperature | -35ºC-+40ºC |
| Seismic Capacity | 8 degree |
