Bare stranded hard-drawn copper conductor is a concentric-lay-stranded conductor consisting of hard-drawn copper wires available in both single layer and multi-layer constructions.
Bare stranded hard-drawn copper conductor is suitable for overhead transmission and distribution networks applications, where the highest electrical conductivity per unit area and good strength-to-weight ratio are required.
Bare stranded hard-drawn copper conductor can be supplied to meet various International Standards as follows:
DIN 48201 / 1
|Conductor construction||Approx. overall diameter||Approx. overall weight||Current Capacity||Minimum breaking load|
|mm²||No. x Ø ( mm )||mm||Kg / km||A||KN|
|10||7 x 1.35||4.1||90||90||4.02|
|16||7 x 1.70||5.1||143||125||6.38|
|25||7 x 2.10||6.3||218||160||9.72|
|35||7 x 2.50||7.5||310||200||13.77|
|50||7 x 3.00||9.0||446||250||19.84|
|50||19 x 1.80||9.0||437||250||19.38|
|70||19 x 2.10||10.5||596||310||26.38|
|95||19 x 2.50||12.5||845||380||37.39|
|120||19 x 2.80||14.0||1060||440||48.90|
|150||37 x 2.25||15.8||1337||510||58.98|
|185||37 x 2.50||17.5||1649||585||72.81|
|240||61 x 2.25||20.3||2209||700||97.23|
|300||61 x 2.50||22.5||2725||800||120.04|
|400||61 x 2.89||26.0||3640||960||160.42|
|500||61 x 3.23||29.1||4545||1110||200.38|
Jiangsu Grand Cable Co., Ltd. was founded in 2002 with a registered capital of 308.88 million CNY(equivalent to 44.13 million USD). The company is located at Section B, Guanlin Industrial ConcentratedArea, Yixing, Wuxi City, Jiangsu 214251, P.R. China, covering an area of 130,000 squaremeters .It owns total assets of 100 million CNY and more than 500 staff members. The annualproduction capacity reaches 2.5 billion CNY .It is one of key enterprises of China Wire & Cable Industry, the National High-Tech Enterprises, the Innovation and Development Pilot Enterprises of Jiangsu Province, the Private Technology Enterprises in Jiangsu Province, keeping Contract and Credit Enterprises and AAA-Grade Credit Enterprise. We have passed ISO9001 Quality System,ISO14001 Environment Management System Certificate and OHSAS 18001 Occupational Health and Safety Management System Certificate.
With more than 300 sets of first-class domestic and imported manufacture and test equipment,Grand Cable can manufacture ten thousand specifications, including Bare Conductors, Earthing Materials, Electric Cables, Solar Cables, Overhead/Aerial Cables, Control Cables, Instrumentation Cables, Power Cables(LV/MV/EHV), Special Cables.
Q: How long does it take get my inquiry replied?
A: Mostly the inquiry will be replied within 12 hours. And the quote will be sent to you in 1-3 days. It depends on the technical parameters and requirements of the cable. We will give you a reasonable and accurate quote.
Q: Can I get samples before placing the order?
A: You will get a sample for free if we have the storage of that cable.
Q: What's the MOQ of your product?
A: The MOQ of our most product is 1000 meters. But if there's any exceptional situation, we can make some negotiations.
Fore More Information, Please do feel free to contact us!
